Knife Edge Disconnect Terminals

ELMEX RAIL TERMINALS

UNIVERSAL RAIL MOUNTED KNIFE EDGE DISCONNECT TERMINAL

KUDT 4


Ratings
Conductor Size
Thickness, T
 : 350 V; 10 Amps
: 0.5 - 4 sq.mm
: 6.5 mm
  • Ideal for Control Signals of C & I package
  • The Faults in the circuit can be simulated by convenient disconnection by operating the hinged lever with the help of screw-driver tip or tester only, during commissioning of the control cubicle.
  • Disconnect operation is offered for testing purpose without disturbing the connected conductors.
  • Screw clamp termination system for internal and field conductor.
  • Clip-on arrangement for mounting on 32 mm and 35 mm channel.
  • Insulation Housing and End Plate made of industrial grade Thermoplastic, Nylon 66.
  • Terminal with Heat Treated Contact Clamps having 1.5 times the Rated Torque withstanding Capacity.

TECHNICAL DATA

DOUBLE DECK TERMINAL : KUDD 4

Ratings
Conductor Size
Insulation Stripping Length
H (when mounted on 32mm Channel) x WxT
H² (when mounted on 32mm Channel) x WxT
Torque required for Screw
Standard Packing
Suitable lug

Insulation Housing
Colour Standard
On request 		: 350 Volts : 10 Amps
: 0.5 sq. mm to 4 sq mm
: 12 mm
: 43.3 mm x 43.5 mm x 6 .5mm
: 38.7mm x 43.5 mm x 6.5 mm
: 5.0 kg.Cm*
: 100 Nos.
: 2.5 sq mm = WPC -7 Dowell’s or equiv.
: 4 sq mm - WPC - 16 Dowell’s or equiv.

: Nylon 66
: Grey
: Red, Yellow, Blue, Black
ACCESSORIES
Mounting Channel
CHS CHK 		Type :
CHS : 32 mm - Thickness : 1.5 mm
CHK : 35 mm - Thickness : 1.0 m
Material: CRCA - Steel
Plating : Alkaline Zinc with Yellow Passivation
Type : Length
CHS-3 : 300mm
CHS-5 : 500mm
CHS-10 : 1mtr.
CHS-20 : 2mtr.
CHK-3 : 300mm
CHK-5 : 500mm
CHK-10 : 1mtr.
Also available in other lengths - on request.
Side Clamps






SCS SCSN SCKN SCUN 		Type :
SCS : Metallic : For CHS, Thickness: 11 mm
- Standard Pkg : 200 Nos.
SCSN : Nylon 66 : For CHS, Thickness : 8.4 mm
- Standard Pkg : 100 Nos.
SCKN : Nylon 66 : For CHK, Thickness : 8 mm
- Standard Pkg : 100 Nos.
SCUN : Nylon 66
- Standard Pkg : 100 Nos
End Plate Type : EP -DT
- Material : Nylon 66
- Thickness : 1.5 mm
- Standard Packing : 100 Nos.
Marking Label
 Type : LABEL - K 6.5
- Standard Packing : 100 Nos.
Snap - on Marking Label
Type : LABEL - A
- 3 Digits / Combination of alphanumeric / Blank
- Material : PVC
- Standard Packing : 100 Nos.
Snap on Type Marking Label
Type : LABEL - K 6.0
- 3 Digits / Combination of alphanumeric / Blank
Group Marking Carrier
Type : GMC
- For Channel type CHS

*This terminal contains Heat Treated Contact Clamp Assembly which can withstand 1.5 times the Torque Value i.e. 8.0 kg cm as compared to 5.0 kg cm mentioned in IEC-947 and VDE 0611.

Technical Specifications may change in line with Technical Advances and industry Standards
